Hot Products

Exported to Europe, Spain, Russia, Japan, Korea, Southeast Asia, the Middle East and so on

Rearview Mirror

Automotive interior and exterior parts

Home appliances mould

Daily necessities mould

Great Wall CH042

Great Wall H6

South Korea's Daewoo EURO6

Japan Hino 280A

Rear door exterior trim

Front door exterior trim

Home appliances

Daily necessities

Rearview Mirror

Automotive interior and exterior parts

Home appliances mould

Daily necessities mould

QUALITY CONTROL

Mainly designs and manufactures automotive endoscopes, mirrors, car intake pipes, automotive interior parts, exterior parts,household appliances and daily necessities.

Rich
Experience

20YEAR OF RICH EXPERIENCE

About Peileixi

Taizhou Huangyan Peileixi Mold Co., Ltd. is located in China's largest mold manufacturing center Huangyan Xicheng Mold City. Only 18 km from Huangyan Airport, close to Hangzhou - Taizhou Expressway, the transportation is very convenient.
The company has more than 60 employees, engineers and senior technicians 10. The company mainly designs and manufactures...

Several elements in plastic molds

1. Parting surface: the contact surface between the plastic mold and the convex mold when it is closed. The choice of its location and form is affected by factors such as product shape and appearance, wall thickness, forming method, post-processing technology, mold type and structure, demoulding method and forming machine structure. 2. Structural parts: that is, the slider, inclined top, and straight top of the complex mold. The design of structural parts is very critical, related to product life, processing cycle, cost, product quality, etc. Therefore, the design of the complex core structure requires the comprehensive ability of the designer, and strives to pursue a simpler, more durable, and more economical design solution. 3. Mold accuracy: namely avoiding jams, positioning, guide posts, positioning pins, etc. The positioning system is related to the appearance quality of the product, mold quality and mold life. According to the different mold structure, choose different positioning methods. The control of positioning accuracy mainly depends on processing. The positioning of the internal mold is mainly considered by the designer, and a more reasonable and easy-to-adjust positioning method is designed. 4. Pouring system: the feeding channel from the nozzle to the cavity of the injection molding machine, including the main runner, branch runner, gate and cold cavity. In particular, the selection of the gate position should be conducive to filling the cavity with molten plastic in a good flow state, and when the mold is opened (except for the hot runner mold), the solid runner and gate cold material attached to the product can be very effective. Easily eject and remove from the mold. 5. Plastic shrinkage rate and factors affecting product dimensional accuracy: such as plastic mold manufacturing and assembly errors, mold wear, etc. In addition, when designing compression molds and injection molds, the matching of process parameters and structural parameters of the molding machine should also be considered.

2021 10-27

Injection molding and temperature issues

The higher the mold temperature, the lower the flow resistance. On many injection molding machines, this naturally means that the flow through the sprue, gate and cavity is faster, because the injection flow control valve used cannot correct this change, and faster filling will result in a greater flow in the sprue and cavity. High effective pressure. May cause flashing. Since the hotter mold does not freeze the plastic that enters the edge area of the flash before the high pressure is formed, the melt will flash around the ejector pin and overflow into the gap of the dividing line. This shows that good injection rate control is required, and some modern flow control programmers can indeed do this. Generally speaking, a higher mold temperature will reduce the amount of plastic that has a condensation layer in the mold cavity, making it easier for the molten material to flow through the mold cavity, thereby increasing the weight of the part and improving the surface quality. At the same time, the mold temperature will also increase the tensile strength of the part. Mold insulation. Many molds, especially thermoplastics, work at relatively high temperatures, such as 80 degrees Celsius or 176 degrees Fahrenheit. If the mold is not insulated, the heat lost to the air and injection molding machine can easily be as much as the heat lost from the injection barrel. Therefore, the mold and the board should be insulated, and if possible, the mold surface should be insulated. If considering the hot runner mold, the heat exchange between the hot runner part and the cooling injection part should be minimized. This can reduce energy loss and warm-up time.

2021 10-27

Model manufacturing is inseparable from high-precision molds, communication that developers cannot ignore

When developing products or trial-manufacturing new products, one should not only focus on R&D and neglect the communication with the model manufacturing unit. After the product design plan is initially determined, there are two advantages to contacting the manufacturer in advance:

2021 10-27

Xiaobian takes you to understand the content of mold processing

With the increasingly fierce competition in the manufacturing field. Shortening the production cycle is a development trend. Some foreign fixture manufacturers have realized the unified benchmark interchange of milling, turning, measuring, EDM and other processes through the use of stable and accurate benchmark systems. It only takes about 1 minute to complete the clamping and alignment on the machine tool, and the repeatability is set within 3μm, which shortens a lot of setting time and improves the actual running time of the machine tool. Facts have proved that this is a necessary condition for modern production. When using the clamping and setting system, it already has the basis for automation.

2021 10-27
